Compound Sliding Table

APEX Code 762

Compound Sliding Table (With swivel graduated Base)
(Size : 6x6", 8x8")

Features :
  • These slide tables have all the features of the standard slide range except the handles are plain (with out calibrations)

Finish : Amazon Green

Specifications
Size in inches 6x6 8x8
Table Size (in mm ) 150x150 200x200
Height overall (in mm) 102 102
Length overall (in mm) 300 350
T-Slot Size (in mm) 10 10
Travel Bothways (in mm) 100x100 125x125
Swivel Graduation 360° 360°
Weight (app. in Kgs) 16 18
